Main Features
Continuous type pre-expander can perform first and second pre-expansion with density from 8-40kg/m.3. By means of insulated stainless steel vessel body, special design fluidized bed, sieving unit, lump breaker and star feeder material transport system, it assures optimal productivity &good quality of pre-expanded materials.
Description | Unit | HJ-CP1000 | HJ-CP800 |
Expansion Vessel | Diameter | mm | 1000 | 800 |
Useable Volume | m3 | 1.25 | 0.8 |
Height | mm | 2000 | 2000 |
Pre-expanding Density | kg/m3 | 8-40 | 8-40 |
Material Outlet Height | mm | 460-1560 | 460-1560 |
Steam | Inlet | DN | 20 | 20 |
Consumption | kg/hr | 180-250 | 150-200 |
Pressure | Mpa | 0.2-0.3 | 0.2-0.3 |
Compressed Air | Inlet | DN | 20 | 20 |
Pressure | Mpa | 0.6-0.7 | 0.6-0.7 |
Condensate | Drain Outlet | DN | 25 | 25 |
First Pre-expansion | Screw Diameter | mm | 80 | 75 |
Screw Speed | rpm | 127 | 127 |
Throughput | kg/hr | 150-500 | 100-300 |
Second Pre-expansion | Screw Diameter | mm | 200 | 180 |
Screw Speed | rpm | 680 | 960 |
Throughput | kg/hr | 80-200 | 50-150 |
Electrical Capacity | First Pre-expansion Motor | kw | 0.55 | 0.55 |
Second Pre-expansion Motor | kw | 0.37 | 0.25 |
Agitator | kw | 4 | 3 |
Fluidizing Bed | kw | 7.74 | 7.74 |
