Home > Product Categories > Industrial Air Cooled Srew Type Chiller Chilling Unit Prices

Industrial Air Cooled Srew Type Chiller Chilling Unit Prices 298 Favorites

Product Categories: Chiller
Packaging Details:1.Wooden case packing;2.Up to the customers.	Trademark:MITEX
Certification: CE,
Payment Terms： L/C, T/T,
FOB: USD $3500/Set	HS Code: 8418692090
Loading Port：Shenzhen

Mitex Automation Machinery Co., Ltd.
Company type： Manufacturer	Credit：
Main products：Mold temperature controller, industrial chiller, hopper dryer, auto loader, dehumidifier, plastic crusher and mixer etc.

Get Quotation

Model	MIC-10A
After-sales Warranty	1 year
Pump Power	1.5KW
Pimp Flow Rate	120KW
Compressor Power	2*3.95KW
Cooling Capacity	31.2KW
Power Supply	380V 3Phase 50Hz/Customized
Water Tank	79L
Certification	CE
Condenser Type	Fin style
Refrigerant	R22/R407C/Customized
Evaporator Type	Tube-in-shell Style
After-sales Service Provided	Video Technical Support, Free Spare Parts

Product Description

Features

The chiller is deployed with P.I.D microcomputer controller, it can control the temperature between +5℃ and +35℃ exactly.2. All electric parts are "Schneider" "Siemens" and " OMRON" brand etc.
Compressor is used "COPELAND" brand which made in USA "Danfoss" brand from Denmark or "Panasonic" brand which made in Japan also newly imported license together with the chiller.
High efficiency cooler and evaporator are passed ISO9002 certification, and also able to save more than 30%of electricity.
Complete with safety protection and error indication system, so it is convenience for operation and maintenance.
The copper tube is used the product of oxygen free welding method for reducing impurities in the interior portion of the tube and increasing the efficiency also the lifetime of compressor.

Product Specification

Model		5A	10A	15A	20A	25A	30A
Freezing capacity	KW	15.6	31.2	46.8	7862.4	93.6	93.6
	Kcal/hr	13416	26832	40248	53664	67080	80496
	Btu/hr	532354	106469	159704	212938	266173	319408
Compressor	power (KW)	3.95	2 x 3.95	2 x 6.3	2 x 7.95	2 x 9.1	3 x 7.95
Refrigerant	Weight KW	2.5	2 x 2.5	2 x 5.5	2 x 6.0	2 x 7.5	3 x 6.0
	Control mode	Thermostatic expansion valve
	type	R22/ R407C (Customized)
Evaporator	Type	Tube in shell
Condenser	Type	Fin style
Condenser	Fan (KW)	0.38	2 x 0.38	2 x 0.78	2 x 0.78	2 x 0.78	3 x 0.78
Water Tank	L	62	79	150	175	175	220
Pump	Power (KW)	0.75	1.5	1.5	2.2	3	4
	Flow rate (L/min)	75	120	208	330	330	550
	Pressure (kg/cm2)	2	2	2	2	2	2
Pipe Coupling	Chillerd water outlet (inch)	1	1.5	2	2	2	2.5
	Chilled water inlet (inch)	1	1.5	2	2	2	2.5
	Water supply port (inch)	0.5	0.5	1	1	1	1
	Over flow port of water tank (inch)	0.5	0.5	0.5	0.5	0.5	0.5
	Drainage port of water tank (inch)	0.5	0.5	1	1	1	1
Protective device	Compressor	Overload relay
	Pump	Overload relay
	Refrigerant circuit	HIgh and low pressure switches
	Cooling water circuit	Water level switch / water flow switch (for option)/ by-pass valve (for option)
Power specification		380v, 3 phase , 50hz (can be customized )
Measures exchange		1KW=860kcal/hr 1RT=3024 kcal/hr 10000 btu/hr= 2520 Kcal/hr
Dimension	LXWXH MM	1450x765x1500	1750x765x1500	2150x1005x1700	2150x1005x1700	2550x1005x1700	3150x1005x1800

Customer Cases

Packing&Shipping

Company Profile

Mitex Automation Machinery Co., Ltd is a national-level High-tech enterprise that established in July, 2007. also a plastic machinery manufacturer specializes in R&D, production and sales to the customer for plant project, design and modern industry 4.0 resolution.

The main products include: centralized feeding system, dehumidifying and drying system, automatic metering and mixing system, crushing and recovery system, mold temperature controlling system and automatic solution etc.
