1.The machine
This series crusher is mainly used in crushing various plastics and rubber such as plastic profile, pipe, stick, wires, film, and wasted rubber products. The granules can be directly supplied for extrusion and injection.
SWP-450 typed plastic crusher is the ideal equipment for the recovery of large profiles and pipes. It has large crushing ability and high output. Its working performance is stable. And it is matched with automatic material feeder which largely improves the machine’s automation degree.
SWP-630 typed plastic crusher is the vacuum container which is used in the crushing of large scaled plastics. It is special equipment for large head materials and plate materials.
2.Features
Adopting deafened low in noise;
Adopting removable bits which can be separately removed and sharpened after getting blunt.
Suitable for smashing all kinds of soft, hard and foamed plastics.
3.Main Technical Parameters
Model | Rotary dia of knife’s (mm) | Rotary knife (pcs) | Fixed knife (pcs) | Sieve (mm) | Crushing Granularity (mm) | Crushing capacity kg) | Match power (kw) | Overall size (mm ) | Machine Weight (kg) |
---|
100 | 100 | 2 | 2 | 6 | 2-4 | 30-50 | 1.5 | 560 x370 x925 |
|
160 | 160 | 6 | 2 | 6–10 | 2–6 | 100–150 | 3 | 790x490x1175 | 300 |
260 | 260 | 3 | 2 | 6–10 | 2–6 | 150–200 | 4 | 800x640x1450 | 300 |
360 | 360 | 3 | 2 | 6–10 | 3–8 | 350–500 | 11 | 1600x1100x 1460 | 1000 |
400 | 400 | 5 | 2 | 6–10 | 3–8 | 200–400 | 11 | 2200 x 900 x 1800 | 1500 |
450 | 450 | 9 | 2 | 10 | 3-8 | 250-400 | 22 | 2180x1020 x1810 | 1500 |
630 | 630 | 60 | 6 | 10 | 3–9 | 700–800 | 30 | 2700x1300 x2860 | 3500 |
800 | 800 | 10 | 4 | 10 | 3-8 | 600-1000 | 55 | 1900 x1500 x3500 | 5500 |
