LLDPE 5 Layer Automatic Cast Stretch Film Extruder Machine For Packing Plastic Wrap CL-80/100/80C

Main Technical Parameter:

Width of Die Head: 2350mm

Width of Film: 2050mm

Thickness of Film: 0.01-0.05mm

Structure of Film Layers: A/B/C or A/C/B/C/A

Liner Speed of Machinery: 200m/min

Max Extrusion Capacity: 420kg/h

Max Rewind Diameter: 400mm

Screw Diameter: 80/100/80mm

L/D Ratio of Screw: 30:1

Motor Power of Main Machine: 45/90/45kw

Total Power: 100-250kw

Overall Dimensions(L*W*H): 12*5.6*4.5m

Total Weight: 17T

Features:

1.The whole line adopts melt metering pump with precision sensor pressure system.

Strictly control plastic extruder output, ensuring to make finished film stable and maintain a uniformity.

2. Cooling roller adopt big diameter design and special double deck runner,

greatly improving the cooling effect in high speed producing process

and ensure the same temperature of cooling roll surface.

3. The whole line comes true fully automatic production, based on traditional automatic cut film,

increase high output, high linear speed and save labour cost.

Application

The stretch film making by this machine is used for packaging goods like pictures.

Certificate

Packing

After-Sales Service

Our professional engineering team is constitutive of excellent technical staff.

We can provide perfect after-sales service in time, give a good technical training to ensure the product in best state perennially.

We will respond to customer`s service requests and complaint in the shortest possible time,

give a clear reply and solution to deal with in time. At the same time,

we sum up customer`s complaint and proposal in order to inherit our advantages,

correct our inadequate. We will commit to improve our services quality, so that our customers will be most satisfied.

We offer warranty on product quality and lifelong maintenance services.
