Product Description
Juice production line
Specifications
1. Juice production line, apple,orange,mongo,pineapple,guava,bissap,grape,banana,olive,coconut,lychee,kiwi,banana, tropical fruits processing
2. All production capacity
3. Factory and hotel are suitable
Main Description
1. Fruit juice plant
2. CE GAP ISO approved
3. From water treatment to package
4. PLC control
5. High efficiency
6. 60- 1500 tons / day
Main technical parameter
1 The processing capacity is varied from 60 tons/day to 1500 tons/day.
2 The line Can deal with similar characteristic of fruits.
3 Using the high efficient of destoner to improve the mango output percentage effectively
4 Using efficient belt juice extractor to improve the juice efficiency and the output percentage.
5 The production process fully automatic PLC control to save labor and Facilitate production management
6 Low-temperature vacuum evaporation ,Maximize reserve the flavor substances and nutrients also save energy.
7 Tubular UHT sterilizer and Aseptic filling machine, produce high-quality aseptic juice products
8 Automatic CIP cleaning ,ensure the entire line equipment of food hygiene and safety requirements
E. Other models
Raw material: | Peach,apricot,plum and other similar flesh fruits with hard seed |
End product: | Nature Juice, juice Concentrate, transparent juice, cloudy juice, canned fruits |
Production capacity: | 20T/D-2000T/D |
Output percentage: | ≥90% |
Solid content | 7~12Brix |
Packing type for end product: | Aseptic Bag/glass Bottle/PET Bottle /gable Top Box/Tetra Pak |
Raw material | Fresh Mango / pineapple |
End product | Transparent juice and cloudy juice, concentrated juice and nfc |
Processing capacity | 60- 1500 tons / day |
Output percentage | 50-75% |
Solid content in NFC | 10-20Brix |
Solid content in concentrated juice | 60~72Brix |
End package | Aseptic bag/gable top box/tetra pak/PET bottle |
Main technical parameter
1. Those lines are applicable for all kinds of hard seed fruits with pulp, such as peach, apricot, plum etc.
2. Flexible configuration to make this line, according to different requirements of the end products, some exact equipments with different functions are flexible chosen, for example: enzymolysis, evaporation etc.
3. According to different investment and product structure prefered, client can require average, middle level or high level processing equipments.
4. End product with pure flavor, bright colour, and high juice output percentage;
5. Whole line with features as high level automatically, low labour intensity, easy operation, safe function and low operation cost.
6. Whole line adopt sanitary design, can clean thoroughly, with high level sanitation.
Accessory equipment
Product application
Company introduction
LONGAMKER is a professional filling,packaging,water treatment solution manufacturer from China with ISO9001:2000 & CE certification who dedicated to manufacture kinds of filling & packaging equipment & water treatment system for beverage & food field.
Built in 2006,LONGAMKER have 4000 square meters modern standard workshop & 40 professional workers,integrate the R&D department,manufacturing department,technical services department and marketing department together,provide the reliable filling system & water treatment system worldwide.
LONGAMKER Manufacture & Provide below filling & treatment system
l PET Bottle,Glass Bottle, Cans,Cups Filling & Packaging Line(Still water,Carbonated soft drink,Juice,Alcohol,Oil etc)
l 1-2 & 3-5 Gallon Jar Bottle Water Plant
l Bottle,Kind of Container Labeling Solutions
l Water Treatment System(RO Pure Water Purifier,UF Mineral Water Purifier,Brackish & Seawater Desalination Plant,Water Softener)
Main Technical parameters |
Model | GFR 16126 | CGFR 18186 | CGFR 24248 | CGFR 32328 | CGFR 404010 | CGFR 484812 | CGFR 606015 | CGFR 808020 |
Heads of washing, filling, sealing | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 48-48-12 | 60-60-15 | 80-80-20 |
Production capacity(bottle/hour) | 3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-18000 | 20000-24000 | 24000-28000 | 36000-40000 |
Suitable bottle height | H=170-320 | Φ=50-100 (330-1500ml) |
|
|
|
|
|
|
Spraying pressure | 0.25-0.3 |
Total Power | 1.5+0.37 | 2.2+0.37 | 3+0.45+ 0.25 | 5.5 | 7.5 | 11 | 15 | 19 |
Overall dimension(L×W×H) | 2300× 1680× 2650 | 2500× 1760× 2650 | 3100× 2100× 2650 | 3800× 2800× 2650 | 4000× 3300× 3400 | 4850× 3650× 3300 | 6500× 5400× 3500 | 7650× 6400× 2700 |
Weight | 2600 | 3500 | 4650 | 6800 | 8500 | 1000 | 12500 | 16000 |
ain Technical parameters |
Model | GFR 16126 | CGFR 18186 | CGFR 24248 | CGFR 32328 | CGFR 404010 | CGFR 484812 | CGFR 606015 | CGFR 808020 |
Heads of washing, filling, sealing | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 48-48-12 | 60-60-15 | 80-80-20 |
Production capacity(bottle/hour) | 3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-18000 | 20000-24000 | 24000-28000 | 36000-40000 |
Suitable bottle height | H=170-320 | Φ=50-100 (330-1500ml) |
|
|
|
|
|
|
Spraying pressure | 0.25-0.3 |
Total Power | 1.5+0.37 | 2.2+0.37 | 3+0.45+ 0.25 | 5.5 | 7.5 | 11 | 15 | 19 |
Overall dimension(L×W×H) | 2300× 1680× 2650 | 2500× 1760× 2650 | 3100× 2100× 2650 | 3800× 2800× 2650 | 4000× 3300× 3400 | 4850× 3650× 3300 | 6500× 5400× 3500 | 7650× 6400× 2700 |
Weight | 2600 | 3500 | 4650 | 6800 | 8500 | 1000 | 12500 | 16000 |
