Shenzhou chair & table injection molding making machine 711 Favorites

Product Categories: From 500T to 700T Injection Machine
Packaging Details:	Trademark:
Certification:
Payment Terms：
FOB:	HS Code:
Loading Port：Shanghai

Zhang Jia Gang SHEN ZHOU Machinery Co., Ltd.
Company type： Manufacturer	Credit：
Main products：Injection molding machine; PET blow molding machine; injection-blow molding machine; extrusion blow molding machine; plastic mould; downstream equipment.

Contact Supplier

Message has been sent successfully.

Post Buying Request

Submit Inquiry

You had already registered,no need join again.

Registered successfully.

Sorry only Buyer can register the activities.

INJECTION UNIT
ITEM	UNIT	VALUE
SCREW DIAMETER	mm	80	85	90
SCREW L/D RATIO	L/D	22.3	21	19.8
Theoretical Shot Volume	cm^3	2141	2418	2710
SHOW WEIGHT(PS)	g	1948	2200	2466
INJECTION PRESSURE	Mpa	188	167	149
THEORETICAL INJECTION RATE(PS)	g/s	427	482	541
PLASTICISING CAPACITY	g/s	80	100	118
SCREW TORQUE	N.m	5170
MAX.SCREW ROTATE SPEED	r/min	150
INJECTION STROKE	mm	425
CLAMPING UNIT
ITEM	UNIT	VALUE
MAX.CLAMPING FORCE	KN	5500
MAX.OPENING STROKER	mm	820
SPACE BETWEEN TIE BARS	mm	810×810
MOULD HEIGHT	mm	350~820
MAX.DAYLIGHT	mm	1640
EJECTOR FORCE	kn	150
EJECTOR STROKE	mm	210
EJECTOR QUANTITY	pc	13
OTHER
ITEM	UNIT	VALUE
PUMP MOTOR POWER	KW	55
PUMP PRESSURE	Mpa	16
HEATING POWER	KW	33
HEATING ZONE		6
SIZE	m	8.4×2.2×2.6
NET WEIGHT	t	23.5
OIL TANK CAPACITY	L	1000
INTERNATIONAL DESIGNATION		5500-4040
