Twin-screw aluminum composite panel extruder
The developed twin-screw aluminum composite panel extruder uses the technology of conical co-rotating twin screw extrusion, which have both advantage of big extrusion pressure of conical counter-rotating twin screw extruder and good plasticization of parallel co-rotating twin screw extruder, in addition, it has stable extrusion pressure of single screw extruder, saving energy obviously, and will become the best equipment to make aluminum composite panel.
At present, the aluminum composite panel is usually extruded by single screw, with main motor power 160-250KW, output around 600-700KG/hour, however, its host engine consume power is more than 300 kwh per ton. Compared to single screw extruder, conical co-rotating twin-screw extruder has obvious advantage of:
1. Saving energy: the SJSZ-85 extruder is able to save 150 kwh per ton, 2000-3000 kwh in total every day, so could return the investment soon;
2. High output: single screw extruder production for 1200-1300 plates per day, the output of SJSZ- 85 twin screw extruder can reach to two or four times of it per day;
3. Good plasticzation: it is able to process not only for A grade, but also for C grade recycled plastic, so it can use higher proportion of recycled plastic or filler than single screw extruder, saving much cost of raw material. It is suitable for high fire retardant ACP production;
4. The machine uses large rotating bearing and large taper screw, so that could bear high torque extruder;
5. We have developed SJSZ-115 extruder with developing SJSZ-135 extruder now, output about 3 tons/ hour;
6. A2 grade fireproof ACP has been developed by extrusion successfully, with performance of environmental friendly and good fire retardant;
7. This kind of machine has been included in catalogue of key energy-saving promotion technology by national development and reform commission, so subsidy of energy-saving can be applied from the government.
8.产品配置及典型客户:
Machine configuration and main cutomer
规格 Description | 85型 | 95型 | 115型 |
加工范围 Processing range | 铝塑板大棚料、回料、高钙防火料 Aluminum plastic sheet shed material ,return material and high Calcium fireproof material |
螺杆大小端直径:(mm) Dia of screw | 85/186 | 95/208 | 115/252 |
螺杆有效长度:(mm) Effective length of screw | 3800 | 4066 | 4600 |
螺杆转速:(r/min) Screw rotating speed | 6-72 | 6-72 | 6-72 |
螺杆机筒材料 Screw barrel material | 38CrMoAlA(镶合金) | 38CrMoAlA(镶合金) | 38CrMoAlA(镶合金) |
主电机功率(kw): Main motor power | 160/4极 | 220/4极 | 315/4极 |
主电机驱动方式 Main motor drive mode | 变频调速 Frequency control | 变频调速 Frequency control | 变频调速 Frequency control |
加热体材质 Heater material | 电磁加铸铝加热器 Electromagnetic and cast aluminium heater | 电磁加铸铝加热器 Electromagnetic and cast aluminium heater | 电磁加铸铝加热器 Electromagnetic and cast aluminium heater |
最大产量Kg/h | 1100 | 1500 | 2350 |
典型客户 | 上海吉祥科技集团公司 SHANGHAI JIXIANG TECHNOLOGY GROUP |
