Poly ether ether ketone sheet,PEEK plate high temperature resistance sheet,virgin peek sheet
Unfilled virgin grade peek plate high temperature resistance peek sheet,High-performance engineering plastic natural peek sheet is a unique semicrystalline, high temperature engineering thermoplastic that is an excellent material for a wide spectrum of applications where thermal, chemical and combustion properties are critical to performance. Especially significant in this regard is PEEK's ability to retain its flexural and tensile properties at very high temperatures-in exces of 250C (482F).
High-performance engineering plastic natural peek sheet has good weldability;Resistant to chemicals;Excellent sliding properites; Excellent dimensional stability; Resistant to high-engery radiation; High abrasion and wear resistant; Good electrical insulator even at high voltages; Hydrolysis resistance even above +200°C;Low coefficient of linear thermal expansion;Outstanding mechanical properties even at high temperatures;Optimized balance of stiffness, thensile strength and impact strength;Continuous operating temperature up to + 260°C and briefly even upto +300°C.
High-performance engineering plastic natural peek sheet are widely used in Wafer Carriers; Seals; Gears; Fittings Aviation;Pump Vanes; Valve Seats; Piston Rings.
Product name | Poly ether ether ketone sheet |
Product size | 1000*610mm(L*W) |
Sheet thickness | 6-50mm |
Sheet color | Beige/Black |
DIMENSIONS(MM) | Material | DIMENSIONS(MM) | Material |
1×610×1220 | PEEK-1000 | 25×610×1220 | PEEK-1000 |
2×610×1220 | PEEK-1000 | 30×610×1220 | PEEK-1000 |
3×610×1220 | PEEK-1000 | 35×610×1220 | PEEK-1000 |
4×610×1220 | PEEK-1000 | 40×610×1220 | PEEK-1000 |
5×610×1220 | PEEK-1000 | 45×610×1220 | PEEK-1000 |
6×610×1220 | PEEK-1000 | 50×610×1220 | PEEK-1000 |
8×610×1220 | PEEK-1000 | 60×610×1220 | PEEK-1000 |
10×610×1220 | PEEK-1000 | 100×610×1220 | PEEK-1000 |
12×610×1220 | PEEK-1000 | 120×610×1220 | PEEK-1000 |
15×610×1220 | PEEK-1000 | 150×610×1220 | PEEK-1000 |
PEEK sheet produce:
|
PEEK package:
|
