Plastic Coating Pipe Machine Feartures:
1.High configuration,main electric parts are importing,
2.The screw surface is carbonized and quenched, electroplated with hard cr. ,Gear tooth surface abrasion resistance.
3.big quantity of extrusion,Low energy consumption of the equipment,
4.high production efficiency than other supplier, high gloss surface,
5.small temperature difference good stability,
6.strong continuity of working, convenient operation, long service life.
Plastic Coating Pipe Machine Technical Parameters:
machine type | MT-65 | MT-70 | MT-80 | MT-90A | MT-90B |
pay-off shaft | double-shaft type |
|
screw diameter | ø65 | ø70 | ø80 | ø90 |
screw L/D |
|
|
|
|
|
MAX. extrusion output | 130kg/h | 150kg/h | 200kg/h | 250kg/h | 280kg/h |
motor power | 25HP | 30HP | 40HP | 50HP | 60HP |
wire diameter | ø1.2-10mm | ø1.5-12mm | ø2.0-20mm | ø3.0-25mm | ø10-40mm |
cooling device | single layer/double layers U type |
|
haul-off power | 5HP | 7.5HP | 10HP |
MAX. line speed | 500m/min | 450m/min | 400m/min | 200m/min |
take-up type/power | double-shaft bundle packaging | ø1000mm-2000mm |
