Home > Product Categories > High Speed SJ-A55 Automatic HD/LDPE Single Layer Film Blowing Machine

High Speed SJ-A55 Automatic HD/LDPE Single Layer Film Blowing Machine 725 Favorites

Product Categories: Single-layer Blowing Film Machine
Packaging Details:Export Stardard Seaworthy Packing	Trademark:Zhuxin
Certification: CE, ISO9001:2008,
Payment Terms： L/C, T/T, Western Union,
FOB: USD $11500/Set	HS Code: 84778000.00
Loading Port：NINGBO

Zhejiang Zhuxin Machinery Co., Ltd
Company type： Manufacturer	Credit：
Main products：film blowing machine, flexo printing machine, bag making machine, paper bag making machine

Model	SJ-A55
Air Ring	1
Center Steady Stick	1
Warranty	1 Year
Take-up Motor	1.5kw
Take-up Speed	10-100m/min
Winding Speed	10-80m/min
Winding Motor	10N.m
Extruder Main Motor	18.5kw
Air Blower	2.2kw
Extruder Average Power Consume	20kw
Extruder Screw L/D Length	28:1/30:1
Extruder Temperature Control	3
Die Temperature Control	3
Extruder Cylinder Cooling	370W×2
Voltage	380V, 50HZ, 3PHASE
Film Width	400-800mm
Outline dimension（L×W×H）	5.5×2.5×5.2m
Take Up Unit Effective Width	800mm
Take Up Unit Height Adjustable	800mm
Take Up Unit Roller Width	900mm
Film Thickness	HD0.009-0.15mm, LDPE0.03-0.15mm
Max Extrusion Output	HD50kg/hr, LD60kg/hr
Suitable Material	HDPE, LDPE, LLDPE
Die Size	HDφ80, LDφ180
After sales service	online support, field installation, commissioning and training
Extruder Screw Material	Sacm -645/38 Crmoala
Extruder Cylinder Material	Sacm -645/38 Crmoala
Model	SJ-A55
Winding Unit Type	Surface friction type
Extruder Screw Diameter	φ55
