CN550-DM PET Preform Injection Machine
CN550-DM PET Preform Injection Machine is customized according to the special molding process of PET plastic machine, screw length-to-diameter ratio increased to 1:25, and the use of wavy design, increase the servo power system, increase the charging motor, making the forming more stable, more efficient.
CN-DM技术规格参数表 Specifications |
说明 | DESCRIPTION | UNTT | CN550-DMPET |
国际公认型号 | International size rating |
|
|
注射装置 | INJECTION UNIT |
| A | A+ |
螺杆直径 | Screw diameter | mm | 90 | 95 |
螺杆长径比 | Screw L/D ratio | L/D | 25 | 25 |
理论注塑容量 | Shot Volume | cm3 | 2569 | 2862 |
注射重量 | Injection weight(PS) | G/克 | 2619 | 2918 |
OZ/盎司 | 92.3 | 103 |
注射速率 | Injection rate | g/s | 681 | 758 |
注射压力 | Injection pressure | Mpa | 154 | 138 |
螺杆转速 | Screw speed | rpm | 0-180 |
合模装置 | CLAMPING UNIT |
|
|
合模力 | Clamping force | KN | 5500 |
移模行程 | Toggle stroke | mm | 900 |
拉杆內距 | Space between tie bars | mm | 880×820 |
容模量 | Mold thickness(Min-Max) | mm | 300-900 |
顶出行程 | Ejector stroke | mm | 250 |
顶出力 | Ejector force | KN | 166 |
其它 | OTHERS |
|
|
最大油泵压力 | Max.pump pressure | Mpa | 16 |
油泵马达功率 | Pump motor power | KW | 90 |
电热功率 | Heater powre | KW | 44 |
机械外形尺寸 | Machine dimension | m | 9.8×2.1×2.23 |
