PVC Semi-auto belling machine DS250B 821 Favorites
Product Categories: Pipe Belling Machine | |
Packaging Details: | Trademark: |
Certification: | |
Payment Terms: | |
FOB: | HS Code: |
Loading Port: |
Changzhou Desheng Mould Factory | |
---|---|
Company type: Manufacturer | Credit: |
Main products: Belling Machine |
Model | DS250B |
Model | DS250 |
Pipe Diameter | 50mm - 250mm |
Pipe Length | 1m – 6m |
Oven | One heating oven, semi-enclosed heated,Stainless steel heating tube with a heat sink |
Pipe Rotary | Clockwise and anti-clockwise |
Heating Power | 10KW |
Compressed air pressure | 0.6Mpa |
Water pressure | 0.4Mpa |
Hydraulic pressure | 6.3Mpa |
U-type | Pushing the mould into pipe directly |
R-type | With ext - pressure and collapsible mandrel |
Cooling type | Water - cooling |
Machine speed | 50S to 150S |
Mould material | U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
Total power | 13KW |
Machine weight | 1700kg |
Machine dimension | 3000mm(L)×1200mm(W)×1950mm(H) |
