PVC double pipe extrusion line
PVC double pipe production line is developed for high output of double pipe extrusion together. The machine with energy efficient conical twin-screw extruder and through special mould one-time extrusion two piece of PVC pipe, effective energy conservation, can improve the production and efficiency, save land and labor costs.The diameter of the extruded pipe is from 16-63mm. It can fully use the extruding capacity of the extruder.
Technology information:
|
Extruder
|
Pipe diameter(mm)
|
Output(kg/hour)
|
Total Power(KW)
|
|
SJZ-51/105
|
16-40
|
120
|
75
|
|
SJZ-55/120
|
20-40
|
150
|
90
|
|
SJZ-65/132
|
25-63
|
250
|
125
|
Note: Informations listed above are for reference only, the production line can be designed by customer’s requirements.
