Use: This production line is used for PP, PE, ABS, PA, PS, crushed material extruding and granule-making. It adopts the two-step structure to meet the double-layer filter purpose. It can effectively remove the impurities from the recycling material and fully exhaust the gas. It can produce ample, consolidated and fine luster granules.
Model | Screw dia.(mm) | Long dia.ratio | Output(kg/h) | Screw rotate speed(r/min) | Power(kw) |
HPD-SJP-80-70 | Φ80、Φ70 | 28:1-10:1 | 70-100 | 70 | 18.5-22 |
HPD-SJP-90-80 | Φ90、Φ85 | 28:1-10:1 | 90-120 | 70 | 22-30 |
HPD-SJP-100-90 | Φ100、Φ95 | 28:1-10:1 | 120-150 | 70 | 30 |
HPD-SJP-120-110 | Φ120、Φ115 | 28:1-10:1 | 200-220 | 70 | 45 |
HPD-SJP-130-120 | Φ130、Φ120 | 28:1-10:1 | 220-250 | 70 | 45-55 |
HPD-SJP-140-130 | Φ140、Φ130 | 28:1-10:1 | 250-300 | 70 | 55-75 |
HPD-SJP-150-140 | Φ150、Φ140 | 28:1-10:1 | 300-450 | 70 | 75-90 |
HPD-SJP-160-150 | Φ160、Φ150 | 28:1-10:1 | 450-600 | 70 | 90-132 |
HPD-SJP-180-170 | Φ180、Φ170 | 28:1-10:1 | 550-800 | 70 | 110-160 |
