DYYF800MM PVC WINDOWS PRFOLE/DOOR BOARDEXTRUSION LINE
We use good quality C model and U model steel as the frame, SIEMENS motor, SIEMENS contactor, OMRON tempertre controller, TTIANYI Button, ABB/FUJI/HOLIP/SHREADER inverter etc. electrical parts.
Choose us, closier to success.
1,PVC profile introduction
PVC profile by PVC resin add various functional additives,after high temperature extrusion molding of industrial and living with PVC products. Add function additives PVC profile has anti-aging,anti-ultraviolet,corrosion resistance,high strength,low price, can replace part of aluminum,steel and other
2,machinery introduction
600PVC profile production line consists of a feeding machine, said SJZ80/156 conical screw extruder, extruding die, YF600 profile shaping table, 600 haul-off machine, profile cutting machine and 600 stacker.
The production line is our company with foreign advanced technology, combined with the actual situation in China research and development, mainly for the PVC profiles of production, change of different size molds can produce such as window profile, PVC panel, PVC trough, PVC flooring and other products, total installed power of 48kW, the largest size 600X60mm.
3.Machinery technical parameters:
Model | YF600 |
Main machinery | SJZ80/156 conical double screw extruder |
Capacity | 300-350kg/h |
Max hauling size | 6000X60mm |
Haling motor | 1.1X2pcs |
Cutting size | 240X00mm |
Machinery speed adjusting | inverter |
other models
model | YF240 | YF400 | YF600 | YF1000 |
main machinery | SJZ55/110 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
output | 120kg/h | 250kg/h | 350kg/h | 500kg/h |
max hauling size | 240X100mm | 400X100mm | 600X80mm | 1000X30mm |
hauling motor | 1.1kwX2 | 1.1kwX2 | 1.1kwX2 | 1.5kwX2 |
cutting size | 240X100 | 400X100 | 600X80 | 1000X30 |
speed adjusting | inverter | inverter | inverter | inverter |
