Application & Features
Apply high performance diffusing device for evenly dispersing hot air,keep even drying temperature for,increase the drying efficiency;
All parts in the material barrel are made of stainless stee.
The material barrel is separated with bottom with convenient and fast material removing and replacing,protect raw material from pollution.
Apply proportion type difference indicating temperature controller and the cooling air blower. assure precise temperature control and extend the serving life.
Specifications
Model | Capacity(Kg) | Power | Erxternal Dimensions | Weight (Kg) |
Heater Power | Blower Power |
JCHD-12E | 12 | 1.8 | 50 | 620*400*820 | 22 |
JCHD-25E | 25 | 3 | 120 | 760*500*1040 | 34 |
JCHD-50E | 50 | 4.5 | 180 | 870*540*1210 | 45 |
JCHD-75E | 75 | 5.5 | 180 | 940*600*1310 | 56 |
JCHD-100E | 100 | 6 | 220 | 1020*730*1410 | 68 |
JCHD-150E | 150 | 7.5 | 300 | 1100*770*1760 | 90 |
JCHD-200E | 200 | 10 | 350 | 1200*850*1830 | 110 |
JCHD-300E | 300 | 15 | 750 | 1420*1000*1880 | 150 |
JCHD-400E | 400 | 15 | 750 | 1480*1060*2000 | 170 |
JCHD-600E | 600 | 20 | 1100 | 1580*1160*2380 | 280 |
JCHD-800E | 800 | 30 | 2200 | 1800*1280*2480 | 360 |
JCHD-1000E | 1000 | 30 | 2200 | 2000*1400*2480 | 500 |
