Application & Features
● Under suction type design and is equipped with a cyclone separator device.
● Effectively improve the transmission capacity of the crushed materiak.
● Separate dust container,facilitate the removal of dust.
● 1pair of 2,pair3fddeing conveyor,can save costs.
● Customers can request matching the capacity of the hopper.
● Host the work of light and alarm devices to keep abreast of the running state;
● Large filters.suction ability.
Mode | Type | Power | (m)Transport Height
| Max feeding ability (kg/h) | Hopper capacity | ld of feeding pipe (mm) | Dimensions |
Main body (LXW X H) cm | Hopper(LXW X H) cm |
JCAL-EG111 | 1拖1 | 1.5 | 4 | 400 | 7.5 | Ф38 | 64*37*103 | 39*30*46 |
JCAL-EG112 | 2 | 6 | 500 | 12 | Ф51 | 43*34*47 |
JCAL-EG113 | 3 | 8 | 600 | 12 | 68*37*103 | 43*34*47 |
JCAL-EG114 | 4 | 9 | 650 | 12 | 43*34*47 |
JCAL-EG115 | 5 | 10 | 700 | 20 | 43*34*58 |
JCAL-EG117 | 7.5 | 12 | 750 | 50 | 52*43*80 |
JCAL-EG121 | 1拖2 | 1.5 | 4 | 650 | 7.5*2 | Ф38 | 64*37*103 | 39*30*46 |
JCAL-EG122 | 2 | 6 | 700 | 12*2 | 43*34*47 |
JCAL-EG113 | 3 | 8 | 900 | 12*2 | 68*37*103 | 43*34*47 |
JCAL-EG125 | 5 | 10 | 1100 | 20*2 | Ф51 | 43*34*58 |
JCAL-EG127 | 7.5 | 12 | 1500 | 50*2 | 52*43*80 |
JCAL-EG132 | 1拖3 | 2 | 6 | 700 | 7.5*3 | Ф38 | 64*37*103 | 52*30*46 |
JCAL-EG133 | 3 | 8 | 900 | 12*3 | 43*34*47 |
JCAL-EG135 | 5 | 10 | 1100 | 20*3 | Ф51 | 43*34*58 |
JCAL-EG137 | 7.5 | 12 | 1500 | 50*3 | 64*37*103 | 52*43*80 |
