Introduction
1. Components
Single color rain boot machine is mainly composed of clamping system, injection system, controlling system, hydraulic system and disc feeder.
2. Products by Machine
Products by one color rain boot machine are PVC double color rain boots for adults/children and PVC safety rain boots (height of rain boots is below 400 mm).
Advantages
1. Our company shares one of the largest sale volumes of rain boot machines in China. Our single color rain boot machine can produce PVC single color rain boots for adults/children and PVC safety rain boots. Our rain boot making machines are popular for their high mechanical strength, powerful clamping system and subtle transformation, etc.
2. The gland system works with single cylinder, which makes pressure high and products well-distributed with little fins. Servo motor is selectable for one color rain boot machine, which helps reduce noise and electric energy consumption by 30%.
3. Single color rain boot machines are controlled with PLC system and data is displayed in touch screen, which realizes industrial human-computer interface operation.
4. Pressure and flow are adjustable in double proportional hydraulic systems. It advances production stability through accurate data and makes operation on hydraulic system easier.
5. The one color rain boot machine is rationally designed and easy to operate. It can be operated even without professors.
6. Mechanical arm is attached to this single color rain boot machine to promise a whole automatic process.
Parameters
Item | Unit | Specification |
Type |
| JIC612 |
Raw Material |
| PVC |
Workstation |
| 12 |
Injection Volume (Max.) | cm3 | 1130 |
Rated Injection Pressure | MPa | 52 |
Heating Power | KW | 8 |
Limit of Temperature | Point | 4 |
Screw Rotation Speed | r.p.m | 0-150 |
Screw Diameter | mm | 90 |
Motor Power | KW | 22 |
Clamping Force | T | 250 |
Mould Size (Max.) | mm | 680 × 360 × 200 |
Machine Size | mm | 5800 × 5050 × 2450 |
Gross Weight | kg | 15000 |
Jili machines have gained good reputations both at home and abroad by virtue of its high-quality, effective and considerate services. Our products have been widely sold to countries like Bengal, Indonesia, Vietnam, Pakistan, Russia, Brazil and countries in Central Asia. If you want to know more about us, contact us please.
