PP, HDPE monofilament rope unit is researched and made by adopting advanced technologies such as PLC program control and frequency-converted speed regulation on the basis to import and absorb Germanic advanced technonolgy. Main electrical components are foreign top-quality products. The feed cylinder and the screw of extruder are especially processed by 38CrMoAlA top quality steel material·The cold and hot water tanks are also made of top-quality stainless steel.The 5-roller draw machine is gearbox style. The drawing and shaping of monofilament are all equipped with foreign advanced hot-air ovens, so that the main technical criteria of this machine can reach up to international advanced level·With the advantages of rapid speed,high production, low energy consupption, good quality of monofilament shaping, the machine has compact structure, easy operation and being safe and reliable.This macjine can be widely used for manufacture all kinds of round yarn with the materials of thermoplastics. Mainly for tap of jump bags and plastic ship rope.
Item | SYL-G70×33-350A Water tank Stretching | SYL-G70×33-350B Hot air oven Stretching |
Screw Dia | Φ70mm | Φ70mm |
Ratio of L/D | 33:1 | 33:1 |
Rotate speed of screw | 0-120m/min | 0-120m/min |
Main machine power | 37Kw | 37Kw |
Output | 110kg/h | 110kg/h |
Pulling power | 4Kw+15Kw | 4Kw+15Kw |
Line speed of drawing | 120m/min | 120m/min |
Drawing ratio | 7-12times | 7-12times |
Number of winder | 32Spindles | 36Spindles |
Holes of spinneret | 28holes | 32holes |
Rou yarn fibre ccope | 3000-6000D | 3000-5000D |
Overall size | 20000×2400×2200mm | 21000×2400×2200mm |
Specification and dimensions are subject to change without prior notice.
