Brief introduction:
The IN-LINE version guarantees high system performance in terms of production speed,management,saving and the best hygiene conditions for food packaging production.integrated new concept and future trend technology control system to ensure production efficiency and stability.
Application:
suitable for PP,HIPS material to produce all kind of plastic products,such as drinking cups,milk cups,water cups,bowls and containers etc.
Features:
1.Man-interface operface, auto assigned proportion feeding,extruding,pressing, forming,stacking and recycling processing are complete production antomatically.
2.Adjusting sheet width online and not required trimming for high utilization.
3.7bar pressure and cutting in mould.
4.Automatic counting and stacking for more sanitary and save labor.
5.Plug and feeding driven by servo motor.
6.High speed: up to 45 analog beats/min.
7.Mould with rapid change device,easy maintenance.
Main technical parameter:
Model | IN-TF55T | IN-TF70T | IN-TF80T |
Main extruder dian | 100mm | 120mm | 150mm |
Max.capacity PS | 350kg/h | 600kg/h | 800kg/h |
Max.capacity PP | 300kg/h | 500kg/h | 700kg/h |
Max.sheet width | 580mm | 735mm | 850mm |
Max.trimming area | 530X300mm | 685X320mm | 780X500mm |
Max.negative depth | 150mm | 180mm | 200mm |
Max.no-load speed | 45cycles/min | 45cycles/min | 40cycles/min |
Forming clamping force | 250kn | 350kn | 750kn |
Total installed power | 300kw | 400kw | 500kw
|
