Application:
It is suitable to form BOPS, HIPS, PVC, PET sheet that can produce boxes, trays, fast-food boxes,dishes and lids etc.
Configuration & Features:
1.Continuous and steady running with speed 15-20 cycles/min
2.Plastic sheet utilization rate is more than 85% after optimize mould design.
3.Mould cutter can guarantee 5 million cycles,can be re-sharpen.
4.More precision temperature control(tolerance:+-0.5 c)
Main technical parameter:
| Max forming area | 510X570mm |
| Max forming depth | 100mm |
| Sheet thickness range | 0.09-1mm |
| Max cutting length | 6000mm |
| Air pressure | 0.7mpa |
| Max working speed | 20cycles/min |
| Preheater power | 21kw
 |
