Basic Equipment
1.Import PLC+human-machine+PLC automatic temperature control model.
2.introduce energy saving valve to the hydraulic system, effective reduce to be the lower working temperature,extend the working life of the hydraulic parts,and save 20% to 40% energy power than the normal type.
3.variety of function used for different product technological requirements: bottom blow and lift,rotation,encapsulation, sub-mould,robot,parison control systen,etc.
Main specifications
| Main parameters | UNIT | LWB80N | LWB90N | LWB100NA |
| Max. product volume | L | 30 | 60 | 90 |
| Dry cycle | Pcs/h | 650 | 500 | 360 |
| Screw diameter | mm | 80 | 90 | 100 |
| Screw L/D ratio | L/D | 25 | 25 | 25 |
| Screw drive power | Kw | 30 | 37 | 45 |
| Screw heating power | 3ØKw | 16 | 21 | 24 |
| Screw heating zone | Zone | 4 | 4 | 4 |
| HDPE output | Kg/h | 100 | 140 | 180 |
| Oil Pump power | Kw | 15 | 18.5 | 22 |
| Clamping force | Kn | 180 | 350 | 500 |
| Mold plate stroke | mm | 400-900 | 500-1200 | 550-1250 |
| Mold platen size | WxH(mm) | 760x660 | 950x900 | 1000x1350 |
| Max. mold size | WxH(mm) | 600x700 | 700x900 | 800x1000 |
| Accumulator capacity | L | 4 | 6.6 | 12 |
| Max. die dimeterd | mm | 300 | 350 | 430 |
| Die heating Zone | 3ØKW | 11.9 | 17 | 20 |
| No. of heating Zone | Zone | 4 | 4 | 5 |
| Blowing pressure | Mpa | 0.8 | 0.8 | 0.8 |
| Air consumption | M3/Min | 0.8 | 1 | 1.2 |
| Cooling water pressure | Mpa | 0.3 | 0.3 | 0.3 |
| Water Consumption | L/Min | 60 | 85 | 100 |
| Machine size | LxWxH(mm) | 4.6x2.4x3.5 | 5.2x2.5x3.9 | 5.5x2.8x4.6 |
| Machine Weight | Ton | 11.7 | 13 | 16
|
