double haul off cutter/plastic cutting machine IS suitable for small diameter various type plastic pipe and profile or board , famous national driving motor and reducer (brand or optional) and durable cutting blades ,independent control table could be adopted.
Feature:
1. Mainly used in small pipe production line;
2. Save you much space in the workshop;
3. Two belts in the haul off and knif-lift used in the cutting machine;
4. Low noise;
5. Haul-off and cutting integral structure design,special synchronous mechanism makes the cutting speed synchronous with the haul-off linear speed;
6. Upper and lower belts are driven separately by double motors controlled by one frequency converter;
7. Quick-changer type rubber block;
8. Professional design of pneumatic system,stepless pressure regulation adjustment
The machine technoical parameters
| Model | GL-40mm |
1 | Form of Haul-off Block | BEIT HAUL OFF |
2 | Electronic Control System | Inverter Control |
3 | Inverter | ABB |
4 | Valid Width | 300 mm |
5 | Valid Length | 2200 mm |
6 | Motor for Haul-off | 3 Kw |
7 | Speed | 0.5-5 M/min |
8 | Clamping Style | Pneumatic |
9 | Shape of Production | PVC Profile |
10 | Motor for Cutting | 1.5 Kw |
11 | Air Compressed Pressure | 0.5-0.7 Mpa |
12 | Clamping Style | Pneumatic,Saw cutting |
