Plastic profile,pipe haul off machine
This machine use the mod of double track cranes draw,silicon controlled stepless speed regulating.It’s mainly matched with plastic extruder,use to extrude and haul every kind of plastic pipe,hollow profile and soft pipe,it’s used widely and easily.
Features
Use double track crane to haul.
Widely use stepless speed regulating,the area of speed regulating is big,the speed of hauling is equality,low-noise,compact structure,beautiful appearance.
Main technical data
Series | DY-1 | DY-2 |
Speed of hauling (m/min) | 0-4 |
Max measurement of hauling (mm) | 120x120 | 150x150 |
Central height of hauling (mm) | 800-1000 | 900-1100 |
Power of hauling (kw) | 1.5 | 3 |
Size (mm) | 1250x650x1600 | 1550x800x1750 |
Weight (kg) | 300 | 500 |
