Features:
1.Automatic mold opening and closing and automatic die to and die out; Reduce workers labor intensity;And also site for women operation.
2.Only need one person to operate the machine at least
3.Every station can be operated individually;Set the technological parameter separately
4.Easy to install mold,only need to fix upper and down mold
5.Automatic switch steam,room temperate water and cold water;short production cycle, high efficiency in order to make sure product dimensional stability and beauty
6.Humanized man-machine interface,PLC controlling;high stability and reliability
7.Totally enclosed operation,safe and reliable without waste water; clean working environment and preventing product secondary pollution
Advantage:
项目 Project | 单位 Company | 规格 Specifications |
原材料 Raw Material |
| EVA | EVA |
工作站位 Work Station Number |
| 6 | 12 |
工作板尺寸 Working Plate Size | mm | 500*420 | 500*420 |
层间距Layer Distance | mm | 260 | 260 |
锁模力 Clamping Force | T | 35 | 35 |
电机功率 Motor Power | kw | 18 | 18 |
加热方式 Heating Method |
| steam | steam |
冷却方式 Cooling Method |
| Room temperate water+cold water | Room temperate water+cold water |
机器尺寸 Machine Size | mm | 6000*2100*2050 | 11000*2100*2050 |
机器毛重 Gross Weight | kg | 8000 | 15000 |
