Brand: Sunbun
Founded: 2002 Year
Structure: Central locking stucture
Central clamping sturcture (China only 2 factory )
Production: 2000 set 2018 years
Tonnage: 140T-2800T
Series: SK Series High speed high precision machine
Equipment:Dossan (kr) 50+ set
DMG 3 set
Mazak center 5 set
Nakamura-tome 3 sets
.........
China clinet : Huawei, ZTE, Haier , Hisense , DELL , Kindly , LOVEL , ZOWEE .....
Advantage of Central locking sturcture (sales points)
1, 100% clampping force use ratio.10%-20% higher than tradtional one
2, Less fins on the finished products
3, 2%-6% raw material saving on the production (deeper cavity more, save more material)
4, effective production for the mold.Mold board and pull rod
5, Open stroke 10%-20% longer than tradtional one
6, Less deformation after cooling
Shortl spacking .......
1, Bigger clampping force , Use smaller machine make bigger productes
2, Bigger Open stroke , Very suit for deep cavity product
| Inject type | Unit | SK140/C400 |
| Screw type |
| A | B | C |
| Screw dia | Mm | 36 | 40 | 45 |
| Screw dia ratio | L/D | 22 | 22 | 20 |
| Injection volume | Cm3 | 188 | 232 | 294 |
| Injection volume (ps) | G | 171 | 211 | 267 |
| Max injection rate to air | Cm3/s | 106 | 131 | 166 |
| Injection pressure | Mpa | 210 | 171 | 135 |
| Injection stroke | Mm | 185 |
| Max injection speed | Mm/s | 105 |
| Screw max speed | R/min | 210 |
|
| Clamping force | Kn | 1400 |
| Open stroke | mm | 430 |
| Bar distance | Mmxmm | 465x418 |
| Max mold | Mm | 460 |
| Min mold | Mm | 180 |
| Ejector stroke | Mm | 130 |
| Ejector force forward | Kn | 45 |
| Ejector force backard | Kn | 30 |
| Thimble qty | Pcs | 1+4 |
|
| System pressure | Mpa | 16 |
| Motor power | Kw | 14 |
| Heater power | Kw | 8.2/8.85 |
| Tem control zone qty | Pcs | 1+4 |
| Bucket capacity | Kg | 25 |
| Oil tank capacity | L | 185 |
| Size | M | 5x1.4x1.8 |
| Weight | T | 4.3
|
