Brief introduction:
Strand cutter plastic granulation line is mainly consisted by the following machinery: feeding system, parallel twin screw(single screw)extruder, Double-station hydraulic screen changer, strand mould, cooling tank, dryer, pelletizer and blowing system(feeding and drying system).etc..
Application:
This recycling production line is the best choice for recycling waste plastic flakes, crushed material and film, etc.
|
单螺杆拉条造粒生产线Single Screw Strand Type Granulation Line
|
|
型号/Model
|
SJ80S
|
SJ90S
|
SJ100S
|
SJ120S
|
SJ160S
|
|
主电机功率/Main motor power
|
55kw
|
90kw
|
132kw
|
160kw
|
220kw
|
|
螺杆直径/Screw Diameter
|
80mm
|
100mm
|
120mm
|
150mm
|
180mm
|
|
造粒方式/Granulation Type
|
Strand type
|
Strand type
|
Strand type
|
Strand type
|
Strand type
|
|
产量/Capacity
|
150-250kg/h
|
250-350kg/h
|
350-500kg/h
|
450-600kg/h
|
600-900kg/h
|
|
平行双螺杆拉条造粒生产线 Parallel Twin Screw Strand Type Granulation Line
|
|
型号/Model
|
SJZ45
|
SJZ51
|
SJZ55
|
SJZ65
|
SJZ80
|
SJZ92
|
|
主电机功率/Main Motor Power
|
15kw
|
18.5kw
|
22kw
|
37kw
|
55kw
|
110kw
|
|
螺杆直径/Screw Diameter
|
45/90
|
51/102
|
55/110
|
65/132
|
80/156
|
92/188
|
|
螺杆旋转/Screw Rotating
|
Counter-rotating, turning outside
|
|
产量/Capacity
|
40-70kg/h
|
60-100kg/h
|
80-150kg/h
|
160-350kg/h
|
220-500kg/h
|
400-700kg/h
|
|
备注：以上规格参数如有变更，恕不另行通知 Remark：Specifications and standard equipment are subject to change without notification
|
