1.The machine
This calendaring machine is of multiple functions, is suitable to produce rigid PVC sheet and semi-rigid PVC sheet, filled plastic sheet, etc. The 5-roll calendaring system consists of main 5-roller calendaring rollers, cooling rollers and other auxiliary machines. The thickness of sheet product can reach to 0.03-0.90mm.
2.Main Technical Parameters
Thickness (mm) | 0.03-0.08mm | 0.08-0.90mm |
---|
Capacity (kg/h) | 350-700kg/h | 700-1300kg/h |
---|
Power (KW) | 55kw*2sets, 75KW*3 sets, Roll line speed: 0-40m/min |
---|
Hard gear reducer | 5 units,drive precision: grade 6 |
---|
Constant temperature oil station | 5sets, heating power: 40KW/Set |
---|
Auxiliary Machine: whole power 458KW, Heating Power: 220KW, Real need= 350kw/h |
