Application:
WPC Wood-plastic profile extrusion line is mainly used to produce WPC (wood plastic composite) profiles, which are widely applied in window and door, floor, furniture, contruction decoration etc.
Questions:mail sales1@zyamachine.com
Technical parameters:
Model | SJSZ51/105 | SJSZ65/132 | SJSZ80/156 |
Screw dia | mm | 51/105 | 65/132 | 80/156 |
Screw max.rotation speed | r/min | 40 | 34.7 | 38 |
Main extruder power | KW | 15 | 35 | 55 |
Barrel heating power | KW | 8 | 24 | 36 |
Central height | mm | 1000 | 1000 | 1000 |
Main products | Frame,Door leaf, Batten | Frame, Door leaf |
Barrel heating and cooling | China heater, Force cooling by air |
Screw heating and cooling | Oil |
Main Technical Specifications of Auxiliary Machine |
Model | YF180 | YF240 | YF300 |
Max.product size | mm | 180 | 240 | 300 |
Draw-off hright | mm | 150 | 150 | 180 |
Draw-off force | KN | 30 | 30 | 30 |
Draw-off speed | m/min | 0-5 | 0-5 | 0-5 |
Auxiliary machine?total power | KW | 30 | 30 | 35 |
Cooling water consumption | M3/h | 6 | 6 | 9 |
Compressed air pressure | Mpa | 0.6 | 0.6 | 0.6 |
